Pipe Service Saddle

Price 23 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

Pipe Service Saddle Specification

Sealing Type
Integrated rubber seal/O-ring

Flexibility
Rigid

Connection Type
Mechanical clamp/threaded/tapping

Bend Radius
Rigid (no bend)

Yield Strength
210-450 MPa (material dependent)

Tensile Strength
320-500 MPa (material dependent)

Diameter
63 mm - 315 mm

Temperature Range
-10C to +60C

Thread Type
BSP/NPT (for outlets)

Tolerance
0.1 mm

Coating Type
Fusion Bonded Epoxy or HDPE lining (if metallic)

Product Type
Cross

Material
Polypropylene / Stainless Steel / Ductile Iron

Connection
Other

Shape
Oval

Standard
Other

Surface Treatment
Other

Section Shape
Oval

Length
Depends on diameter, typically 130-300 mm

Thickness
4-12 mm (depending on size)

Color
Black

Usage
Joining/Branching pipeline connections

Rated Pressure
PN 16 (up to 16 bar)

Application
Water Supply, Irrigation, Plumbing, Industrial Fluid Transfer

Material Grade
PE 80, PE 100, SS304, Ductile Iron GGG50 (varies by variant)

Weight
0.4 - 3.2 kg (varies by size)

Suitable Pipes
PE, PVC, Steel, Ductile Iron

Leakage Test Pressure
Upto 24 bar

Life Expectancy
> 15 years under standard conditions

End Connection
Drilled saddle outtake

Fixing Type
Double strap / single strap type

Clamping Mechanism
Heavy duty steel bolts with corrosion-resistant nuts

Max Installation Torque
25 Nm - 55 Nm

Compliance
ISO 4427 / IS 4984 / AWWA C800 (as requested)

Corrosion Resistance
High

Outlet Size
1/2 inch to 2 inch threaded (varies on model)

Gasket Material
EPDM / NBR rubber

Pipe Service Saddle Trade Information

Minimum Order Quantity
25 Pieces

Supply Ability
10000 Pieces Per Day

Delivery Time
1 Days

Main Domestic Market
All India

About Pipe Service Saddle

Purchase the hot-selling Pipe Service Saddle with Clamping Mechanismengineered for unparalleled performance and reliability in demanding pipeline applications. This redoubtable saddle features heavy-duty steel bolts with corrosion-resistant nuts and accommodates outlet sizes from 1/2 inch to 2 inches (threaded). With a maximum installation torque of 25 Nm to 55 Nm, and a life expectancy exceeding 15 years, it is remarked for its robust construction, superior EPDM/NBR gasket, and compliance with ISO 4427, IS 4984, and AWWA C800 standards. Order now for guaranteed quality and seamless pipeline integration.

Versatile Application and Standout Features

This Pipe Service Saddle is designed for use in joining or branching pipeline connections across water supply, irrigation, plumbing, and industrial fluid transfer systems. Its direction of use is mechanical clamping to create secure tapping or branch connections on PE, PVC, steel, and ductile iron pipes. Noteworthy features include high corrosion resistance, integrated rubber seals for leak-tight connections, an oval shape for enhanced flow, and compatibility with various material grades, ensuring impeccable sealing and structural strength.

Packing, Dispatch & Sample Information

Packing & Dispatch of the Pipe Service Saddle adheres to best-in-class standards, with each unit securely wrapped to prevent transit damage. FOB port facilities are available for flexible international shipments. For domestic mar or international partners evaluating the proposal amount, sample units are available upon request, facilitating product assessment before proceeding with bulk orders. Each consignment is accompanied by detailed documentation and robust packaging, ensuring the product arrives ready for immediate installation.

FAQs of Pipe Service Saddle:

Q: How do I select the appropriate Pipe Service Saddle for my application?

A: Choose the saddle based on pipe size, outlet thread type (BSP/NPT), material requirements (PE, SS304, Ductile Iron), and pressure/temperature ratings. Consult the technical datasheet or contact our support for tailored recommendations.

Q: What is the installation process for the Pipe Service Saddle?

A: Secure the saddle onto the pipe using the clamping mechanism, tighten bolts to the specified torque (25-55 Nm), and ensure the integrated gasket is properly seated for a reliable, leak-free connection. Step-by-step instructions are provided with each unit.

Q: Where can the Pipe Service Saddle be used?

A: The saddle is suitable for water supply, irrigation, plumbing, and various industrial fluid transfer systems. Its compatibility with PE, PVC, steel, and ductile iron pipes makes it ideal for domestic and industrial settings.

Q: What are the benefits of using this saddle over conventional methods?

A: This saddle offers quick installation, high leak resistance due to integrated seals, corrosion-proof hardware, and compliance with international quality standards, reducing downtime and ensuring a secure branch connection.

Q: Is a sample available before placing a bulk order?

A: Yes, sample units are available for evaluation. Please request a sample to review product performance, fit, and suitability in your application before confirming your proposal amount for bulk purchasing.
