Polypropylene 3 Piece Flange End Ball Valve

About Polypropylene 3 Piece Flange End Ball Valve

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Versatile Sizing and Secure Flange Connections

Available in sizes from 1/2" to 12", this 3-piece ball valve features 150 class flanges to ensure robust, secure fitting in a range of piping systems. Polypropylene construction makes it suitable for both small and large-scale industrial and water applications, providing flexibility for diverse operational requirements.


Durable Polypropylene Design for Demanding Applications

Manufactured with high-quality polypropylene, this ball valve resists corrosion, chemical attack, and stress cracking. Its construction allows it to withstand temperatures reaching up to 80C and medium pressure settings, making it an excellent choice for industrial and municipal water systems where longevity and reliability are critical.
