pp ball valve 2.5"

About pp ball valve 2.5"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Teflon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEFLON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEFLON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Durable Polypropylene Construction

Constructed from superior-grade polypropylene (PP), this ball valve offers high corrosion resistance, ensuring longevity and optimal performance even with constant exposure to water and various industrial fluids. The sturdy white finish further enhances its durability during prolonged usage.


Versatile Industrial & Water Applications

Designed for both industrial and water supply systems, this 2.5" ball valve is ideal for pipeline networks in factories, treatment plants, and municipal supply. Its structure facilitates easy installation, reliability, and low maintenance across various operational settings.


Precision Engineered for Safety and Reliability

With a maximum media temperature of 80C and medium pressure tolerance, this valve ensures secure shutoff and reliable flow control. The 150 class flanged connection guarantees a tight seal and simplified mounting for diverse pipeline requirements.
