Send Inquiry

Request To Call Back

PP NRV Ball Valve

Price 3200 INR/ Number

Get a Price/Quote

PP NRV Ball Valve Specification

Channels
Intentional & Domestic Market

Structure
Ball

Connection
Flanged

Caliber
Gokul Poly Valves Pvt Ltd

Pressure
Medium Pressure

Material
Plastic

Usage
Industrial & Water Application

Size
1" To 12"

Media
Water

Temperature of Media
80 Celsius (oC)

Product Type
PP Non Return Valve Flanged

Port Size
1" To 12"

Flange
150 class

Color
White

Finish
Polypropylene (PP)

Application
industrial and water application

PP NRV Ball Valve Trade Information

Minimum Order Quantity
10 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
10 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About PP NRV Ball Valve

Technical Specification Material Of Construction PP (Polypropylene) Construction Ball type design, soft seated, 2 Piece Design Design 2 Piece Design Connection End Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD. Size Range 25MM to 315MM Test pressure 10 kg./cm2 Max working temp 70 c (consistently) Standard As per manufacturer Material Specification No. DESCRIPTION MATERIAL QTY. 1) Top Body Polypropylene 1 2) Bottom body Polypropylene 1 3) Ball Polypropylene 1 4) Ball Ring Polypropylene 1 5) Seat Ring Neoprene Rubber 1 6) Stud, Nut & Washer SS Req.

FAQs of PP NRV Ball Valve:

Q: What is the temperature limit for the PP NRV Ball Valve?

A: The PP NRV Ball Valve can handle media temperatures up to 80C.

Q: What material is used in manufacturing the PP NRV Ball Valve?

A: The PP NRV Ball Valve is made of Plastic with a Polypropylene (PP) finish.

Q: What is the range of port sizes available for the PP NRV Ball Valve?

A: The PP NRV Ball Valve is available in port sizes ranging from 1" to 12".

Q: What type of connection does the PP NRV Ball Valve have?

A: The PP NRV Ball Valve has a flanged connection rated at 150 class.

Q: What are the primary applications for the PP NRV Ball Valve?

A: The PP NRV Ball Valve is designed for both industrial and water applications.
