PP Sight Glass Valve

450 INR/Number

Get a Price/Quote

Request To Call Back Send Inquiry

PP Sight Glass Valve Price And Quantity

FOB Port Ahmedabad
Payment Terms Cash Advance (CA) Cash in Advance (CID) Cheque
Supply Ability 10 Number Per Day
Delivery Time 1 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Box Packing
Main Export Market(s) Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
Main Domestic Market All India
Certifications ISO & Material Test Certificate

Material Of Construction	PP (Polypropylene)	Construction	3 piece design, full bore, Teflon seated, borosil glass
Design	3 piece design	Test pressure	8kg
Max working temp	60 c (consistently)	Size Range	ï-15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturer

No.	DESCRIPTION	MATERIAL	QTY.
1)	Side Piece/ Connector	Polypropylene	2
2)	Glss Tube	Glass ( BOROSIL)	1
3)	Crisent Ring	PTFE (Teflon)	2
4)	Stud	M.S./ S.S.	REQ
5)	Nuts wisher	M.S./ S.S.	REQ
6)	Nut Cap	Polypropylene	REQ
7)	Stud Tube	PP / PVC Coated	REQ
