PVDF Screwed End Ball Valve

Price 28 INR/ Piece

Get a Price/Quote

MOQ : 25 Pieces

PVDF Screwed End Ball Valve Specification

Temperature Range
-20C to +120C

Yield Strength
30 MPa

Thread Type
BSP (British Standard Pipe)

Tensile Strength
40 MPa

Flexibility
Rigid

Sealing Type
PTFE Seat Sealing

Diameter
25 mm To 315 mm

Coating Type
Uncoated

Connection Type
Threaded

Tolerance
0.1 mm

Product Type
Screwed End Ball Valve

Material
Plastic

Connection
Other

Shape
Other

Standard
Other

Surface Treatment
Other

Outer Diameter
25 mm To 315 mm Millimeter (mm)

Section Shape
Cylindrical

Length
Standard Length as per size

Thickness
3 mm 12 mm

Color
white

Usage
Chemical, Water, and Industrial Applications

Rated Pressure
PN10

Application
Flow Control in Pipes, Industrial Piping Systems

Material Grade
Virgin PVDF

PVDF Screwed End Ball Valve Trade Information

Minimum Order Quantity
25 Pieces

Supply Ability
1000 Pieces Per Day

Delivery Time
1 Days

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About PVDF Screwed End Ball Valve

PVDF Screwed End Ball Valve

Application	ALL
Model No.	005
Design	3 PIC
Connector Type	FLANGEND
Model	3 PICE BALL VALVESA
Size	25MM TO 315MM
Color	WHITE
Brand	GOKUL
Media	Water
Pressure	Medium Pressure
Power	Manual
Automation Grade	Manual
Temperature of Media	High Temperature
WOG Rating	150
Port Size	25MM TO 315MM
Ball Seat	PP
Capacity	5 KG.
Bore Type	FUUL
Coating	PP
Material Grade	PP
Range	15MM TO 315MM
Packaging Type	BOX
Shape	FLANGEND
Diameter	25MM TO 315MM
Valve Size	25MM TO 200MM
Temperature	150
Warranty	1 YAS
Usage/Application	industries
Lever Type	HEND
Inner Diameter	25MM TO 315MM
Single Union	3 PICE VALVE
Flange Size	25MM TO 315MM
Working Temperature	100
I deal in	New Only
Grade	PP
Material	Plastic
Connection endï	Screwed Endï

Exceptional Chemical Resistance and Safety

Crafted from virgin PVDF, this ball valve delivers superior resistance against corrosive chemicals, acids, and water, ensuring long-term leak-free operation. The bubble-tight shutoff mechanism further guarantees safety in critical flow control applications, minimizing risks of leaks and contamination in industrial environments.

Versatile Installation and Operation

Designed for flexibility, the PVDF ball valve can be mounted both horizontally and vertically, accommodating diverse piping system layouts. With manual control and a rigid, cylindrical body, users benefit from straightforward operation, whether regulating flow in chemical processing facilities or water treatment plants.

FAQs of PVDF Screwed End Ball Valve:

Q: How do I install the PVDF Screwed End Ball Valve in my piping system?

A: To install, align the valve with the threaded pipe ends, ensuring the BSP threads match. Tighten the connections securely to avoid leaks. The valve can be mounted in either horizontal or vertical positions, depending on your system layout.

Q: What media are compatible with this PVDF ball valve?

A: This valve is suitable for a wide range of media, including water, chemicals, and acids, thanks to the excellent corrosion resistance of its virgin PVDF body and PTFE sealing.

Q: When should I use a PVDF Screwed End Ball Valve over other materials?

A: Select a PVDF ball valve when you require high resistance to corrosive chemicals, elevated temperatures (up to +120C), and reliable, leak-proof shutoff in industrial or chemical processing applications.

Q: Where is this valve commonly used?

A: PVDF ball valves are commonly installed in chemical plants, water treatment facilities, and various industrial piping systems, wherever durable, corrosion-resistant flow control is necessary.

Q: What is the process for manufacturing this ball valve?

A: The valve is produced using injection moulding, which ensures tight dimensional tolerances (0.1 mm) and uniform wall thickness for dependable operating performance.

Q: How does the PTFE seat sealing benefit valve operation?

A: PTFE seat sealing ensures bubble-tight shutoff, preventing leaks even under maximum working pressure. This guarantees safer operation, particularly when handling hazardous substances.
