Flanged Polypropylene Ball Valve

About Flanged Polypropylene Ball Valve

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Robust Polypropylene Construction

Manufactured from high-grade polypropylene, these flanged ball valves are engineered for longevity and resistance to corrosion. Their plastic build is especially adept at handling water and various industrial fluids, making them ideal for demanding environments. The smooth, white finish also contributes to their resilience in medium pressure conditions.


Versatile Size and Port Range

With a port size variation from 1/2" to 12", the valves offer remarkable flexibility for a wide array of pipeline systems. This extensive size range ensures that they can be used in everything from compact water lines to large industrial applications, delivering precise flow regulation and ease of maintenance.
