Gokul polypropylene Ball Screwed End Valve Gokul polypropylene Ball Screwed End Valve Gokul polypropylene Ball Screwed End Valve Gokul polypropylene Ball Screwed End Valve Gokul polypropylene Ball Screwed End Valve Gokul polypropylene Ball Screwed End Valve

Gokul polypropylene Ball Screwed End Valve

2850 INR/Number

Product Details:

  • Size 1/2" To 4"
  • Channels Intentional & Domestic Market
  • Caliber Gokul Poly Valves Pvt Ltd
  • Product Type PP Screw End Ball Valve
  • Color White
  • Pressure Medium Pressure
  • Connection Screw End (BSP Threaded)
  • Click to view more
X

Gokul polypropylene Ball Screwed End Valve Price And Quantity

  • 2850.00 - 2850.00 INR/Number
  • 10 Number
  • 2850 INR/Number

Gokul polypropylene Ball Screwed End Valve Product Specifications

  • industrial and water application
  • Polypropylene (PP)
  • White
  • PP Screw End Ball Valve
  • BSP Threaded
  • Gokul Poly Valves Pvt Ltd
  • 80 Celsius (oC)
  • Intentional & Domestic Market
  • 1/2" To 4"
  • 1/2" To 4"
  • Water
  • Industrial & Water Application
  • Ball
  • Screw End (BSP Threaded)
  • Medium Pressure

Gokul polypropylene Ball Screwed End Valve Trade Information

  • Ahmedabad
  • Cash Advance (CA) Cash in Advance (CID) Cheque
  • 20 Number Per Day
  • 1 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Box Packing
  • Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
  • All India
  • ISO & Material Test Certificate

Product Description

Technical Specification

Material Of Construction PP (Polypropylene) Construction 3 piece design, 1 piece stem (spindle), full bore, Teflon seated
Design 3 piece design Test pressure 08 kg./cm2
Max working temp 70 c (consistently) Size Range "- 15MM TO 100MM- 4ï
Connection End Screw end (BSP thread) Standard As per manufacturer

Material Specification

NO. DESCRIPTION QTY. MATERIAL
1) Flanged end 2 Polypropylene
2) Body 1 Polypropylene
3) Ball 1 Polypropylene
4) Stem/Spindal 1 Polypropylene With M.S. /S.S
5) Seat Ring 2 PTFE (TEFLON)
6) Body"O"Ring 2 Neoprene
7) Stem Seal Ring 1 PTFE (TEFLON)
8) Stem "O" Ring 1 Neoprene
9) Stud, Nut & Washer REQ M.S. Zinc Plated/S.S
10) Nut Cap REQ Polypropylene.
11) Handle 1 M.S. PP Coated.
12) Handle Hex. Pin 1 M.S./ S.S.
13) Handle Cap 1 Polypropylene.
