Gokul PP Ball Valve 6"

About Gokul PP Ball Valve 6"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Industry-Leading Design

The Gokul PP Ball Valve features advanced ball structure engineering that guarantees smooth and consistent flow control. With a flanged 150 class connection, installation is secure and long-lasting. Designed for both intentional and domestic markets, it is suitable for a range of fluid handling scenarios.


Superior Material & Finish

Made from premium-grade polypropylene (PP), this valve offers exceptional resistance to chemicals and corrosion, ensuring longevity in demanding environments. The white finish enhances its appeal and visibility, making it easier to inspect and maintain.


Optimal Performance in Water and Industrial Use

Operating at temperatures up to 80C, the Gokul PP Ball Valve is built for medium pressure water and industrial systems. Its versatile sizing and durable construction make it a preferred choice for both local and export markets.
