Gokul Screwed PP Non Return valve Gokul Screwed PP Non Return valve Gokul Screwed PP Non Return valve Gokul Screwed PP Non Return valve Gokul Screwed PP Non Return valve Gokul Screwed PP Non Return valve

Gokul Screwed PP Non Return valve

1340 INR/Number
Get a Price/Quote

Product Details:

  • Structure Ball
  • Usage Industrial & Water Application
  • Color White
  • Size 1" To 4"
  • Channels Intentional & Domestic Market
  • Product Type PP Non Return Valve Screw End
  • Caliber Gokul Poly Valves Pvt Ltd
  • Click to view more
Request To Call Back Send Inquiry
X

Gokul Screwed PP Non Return valve Price And Quantity

  • 10 Number
  • 1340.00 - 1340.00 INR/Number
  • 1340 INR/Number

Gokul Screwed PP Non Return valve Product Specifications

  • 1" To 4"
  • Gokul Poly Valves Pvt Ltd
  • PP Non Return Valve Screw End
  • Intentional & Domestic Market
  • 1" To 4"
  • Ball
  • Polypropylene (PP)
  • White
  • Industrial & Water Application
  • 80 Celsius (oC)
  • Water
  • Screw End (BSP Threaded)
  • Plastic
  • industrial and water application
  • Medium Pressure
  • BSP Threaded

Gokul Screwed PP Non Return valve Trade Information

  • Ahmedabad
  • Cash Advance (CA) Cash in Advance (CID) Cheque
  • 10 Number Per Day
  • 1 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Box Packing
  • Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
  • All India
  • ISO & Material Test Certificate

Product Description

Technical Specification

Material Of Construction PP (Polypropylene) Construction Ball type design, soft seated, 2 Piece Design
Design 2 Piece Design Connection End Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.
Size Range 25MM to 315MM Test pressure 10 kg./cm2
Max working temp 70 c (consistently) Standard As per manufacturer

Material Specification

No. DESCRIPTION MATERIAL QTY
1) Top Body Polypropylene 1
2) Bottam Body Polypropylene 1
3) Ball Polypropylene 1
4) Ball Ring Polypropylene 1
5) Seat Ring Neoprene Rubber 1
6) Stud, Nut & Washer SS Req
