Polypropylene Diaphragm Threaded Valve

Price 325 INR/ Number

Get a Price/Quote

Polypropylene Diaphragm Threaded Valve Specification

  • Pressure
  • Medium Pressure
  • Channels
  • Intentional & Domestic Market
  • Structure
  • Ball
  • Connection
  • Screw End (BSP Threaded)
  • Caliber
  • Gokul Poly Valves Pvt Ltd
  • Material
  • Plastic
  • Usage
  • Industrial & Water Application
  • Media
  • Water
  • Size
  • 1/2" To 1"
  • Temperature of Media
  • 80 Celsius (oC)
  • Product Type
  • PP Diaphragm Valve Screw End
  • Port Size
  • 1/2" To 1"
  • Flange
  • BSP Threaded
  • Color
  • White
  • Finish
  • Polypropylene (PP)
  • Application
  • industrial and water application


Polypropylene Diaphragm Threaded Valve Trade Information

  • Minimum Order Quantity
  • 10 Number
  • FOB Port
  • Ahmedabad
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque
  • Supply Ability
  • 10 Per Day
  • Delivery Time
  • 1 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Box Packing
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISOO & Material Test Certificate


About Polypropylene Diaphragm Threaded Valve

Technical Specification Material Of Construction PP (Polypropylene) Construction weir type design,Soft seated, raising stem Design 2 Piece Design Connection End Screw end (BSP thread) Size Range 15MM to 150MM Test pressure 6 kg./cm2 Max working temp 70 c (consistently) Standard As per manufacturer Material Specification No. DESCRIPTION MATERIAL QTY. 1) Body Polypropylene 1 2) Bonnet Polypropylene 1 3) Hand wheel Polypropylene 1 4) Diaphragm Neoprene Rubber 1 5) Compressor PP 1 6) Stem / Spindel M.S. /Brass 1 7) Nut M.S./ S.S. 1 8) Pin M.S./ S.S. 1 9) Bolt, Nut, Washer M.S./ S.S. REQ 10) Cap Polypropylene 1

FAQs of Polypropylene Diaphragm Threaded Valve:


Q: What are the available sizes for the Polypropylene Diaphragm Threaded Valve?

A: The Polypropylene Diaphragm Threaded Valve is available in sizes ranging from 1/2" to 1".

Q: What type of connection does this valve use?

A: The valve uses a screw end (BSP threaded) connection.

Q: What is the maximum temperature of media this valve can handle?

A: The valve can handle media temperatures up to 80C.

Q: Which applications is this valve suitable for?

A: The valve is suitable for industrial and water applications.

Q: What is the material used for the construction of the valve?

A: The valve is made of polypropylene (PP), a type of plastic.

Q: What is the pressure rating of the Polypropylene Diaphragm Threaded Valve?

A: The valve is suitable for medium pressure applications.

Q: What market channels does this valve cater to?

A: This valve is designed for both intentional and domestic markets.
