Pp Ball Valve Flange End 1"

About Pp Ball Valve Flange End 1"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Exceptional Build Quality

Engineered with high-quality polypropylene (PP), this valve is built for longevity. Its chemical resistance makes it ideal for demanding environments, ensuring safety and reliability. The white finish adds to its clean appearance for industrial and water installation aesthetics.


Versatile Application

Designed for both industrial and water distribution systems, the PP Ball Valve Flange End adapts to a variety of use-cases. Its 1-25MM size and 150-class flange make installation straightforward across different operational setups.


Optimal Performance in Harsh Conditions

With the capacity to handle medium pressure and media temperatures up to 80C, this valve performs reliably in rigorous conditions. Its precision ball structure ensures smooth water regulation and efficient maintenance operations.
