Pp Ball Valve Flange End 10"

About Pp Ball Valve Flange End 10"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Advanced Polypropylene Construction

The ball valve is crafted from premium polypropylene, delivering excellent resistance to chemicals and corrosion. This ensures suitability for a wide range of water and industrial applications, offering longevity and reliability even in harsh operating environments. The materials durability makes the valve a cost-effective choice for both intentional and domestic markets.


Secure Flanged Connections

Featuring a 150 class flanged design, the valve guarantees tight and reliable connections. Installation is simplified for end users, reducing the risk of leaks and enabling straightforward maintenance. The flanged ends are compatible with a variety of piping standards, enhancing versatility for diverse industrial setups.


Versatile Application and Performance

Designed for use in water and industrial processes, the valve handles medium pressure and temperatures up to 80C. Its structure promotes consistent flow control, making it suitable for a variety of sectors. This product serves as an efficient solution for both exporters and domestic suppliers across India.
