PP Non Return Valve Flange End 1.5"

Price 560 INR/ Number

Get a Price/Quote

PP Non Return Valve Flange End 1.5" Specification

Channels
Intentional & Domestic Market

Connection
Flanged

Structure
Ball

Caliber
Gokul Poly Valves Pvt Ltd

Pressure
Medium Pressure

Usage
Industrial & Water Application

Size
1.5"-40mm

Media
Water

Temperature of Media
80 Celsius (oC)

Product Type
PP Non Return Valve Flanged

Port Size
1.5"-40mm

Flange
150 class

Color
White

Finish
Polypropylene (PP)

Application
industrial and water application

PP Non Return Valve Flange End 1.5" Trade Information

Minimum Order Quantity
10 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
10 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About PP Non Return Valve Flange End 1.5"

TECHNICAL SPECIFICATION
Material Of Construction	PP (Polypropylene) / PVDF
Design	2 Piece Design
Size Range	25 mm to 315 mm
Maximum working temp	80 c (consistently)
Construction	Ball type design, soft seated, 2 Piece Design
Connection End	Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.
Test pressure	10 kg./cm2
Standard	As per manufactuer''s

Reliable Flow Control for Industrial & Water Applications

Engineered to support consistent water flow while preventing backflow, this PP non-return valve is suitable for a broad range of industrial and water-related installations. The robust polypropylene construction delivers dependable performance even under medium pressure and moderate temperatures, making it an asset for various piping systems.

Designed for Simple Installation & Maintenance

Featuring a flanged end connection, this valve facilitates easy installation and removal, minimizing downtime during maintenance. Its ball structure allows for smooth operation and enhanced sealing, reducing the risk of leaks and extending service life.

FAQs of PP Non Return Valve Flange End 1.5":

Q: How is the PP Non Return Valve Flange End 1.5" installed in industrial and water applications?

A: The valve utilizes a flanged connection (150 class) for straightforward installation on compatible piping systems. It should be fitted in line with the intended flow direction to prevent water from reversing direction, ensuring efficient operation in industrial and water applications.

Q: What benefits does polypropylene (PP) construction provide for this valve?

A: Polypropylene offers notable resistance to corrosion, chemicals, and sediment buildup. This makes the valve ideal for handling water in demanding industrial settings, ensuring longevity and minimal maintenance requirements.

Q: When should I use a non return valve with a ball structure?

A: A ball-structured non return valve is recommended when you need reliable prevention of backflow in medium pressure environments. It supports smooth, unobstructed flow and is useful in scenarios where water purity and system integrity are essential.

Q: Where can this valve be applied most effectively?

A: It is highly effective in both domestic and industrial water systems, including pipelines that require secure backflow prevention. The product fits installations requiring medium pressure and a port size of 1.5" (40mm).

Q: What is the process for maintaining a PP non return valve?

A: Routine visual inspections and cleaning of debris are recommended. The flanged design permits easy removal for maintenance, allowing quick access to internal components for cleaning or replacement if needed.

Q: What is the maximum temperature and pressure this valve can withstand?

A: The valve is rated for mediums with temperatures up to 80C and is designed for medium pressure applications, ensuring safe and reliable operation in most water-handling environments.

Q: What advantages do I gain by choosing Gokul Poly Valves Pvt Ltd as a supplier?

A: Gokul Poly Valves Pvt Ltd ensures high-quality manufacturing standards, comprehensive service support, and reliable product exportation, positioning them as a trusted partner for domestic and international market requirements in India.
