Gokul Polypropylene Diaphragm Valve Flange End 3/4"

About Gokul Polypropylene Diaphragm Valve Flange End 3/4"

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	weir type design,Soft seated, raising stem
Design	2 Piece Design	Connection End	Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.
Size Range	15MM to 150MM	Test pressure	6 kg./cm2
Max working temp	70 c (consistently)	Standard	As per manufacturer

Material Specification

No.	DESCRIPTION	MATERIAL	QTY.
1)	Body	Polypropylene	1
2)	Bonnet	Polypropylene	1
3)	Hand wheel	Polypropylene	1
4)	Diaphragm	Neoprene Rubber	1
5)	Compressor	PP	1
6)	Stem / Spindel	M.S. /Brass	1
7)	Nut	M.S./ S.S.	1
8)	Pin	M.S./ S.S.	1
9)	Bolt, Nut, Washer	M.S./ S.S.	REQ
10)	Cap	Polypropylene	1

Versatile Valve Design

Designed with a robust polypropylene structure, the Gokul diaphragm valve features a 3/4" flange end that supports medium pressure conditions. This makes it adaptable for a range of industrial and domestic water supply systems, ensuring reliable operation in various environments.


Reliable Performance for Water Applications

The valves chemical-resistant plastic construction, along with a secure flanged connection, provides safe and consistent water flow management. It is suitable for projects where maintaining clean and uncontaminated water passages is essential, all while handling temperatures up to 80C.


Trusted Manufacturer and Exporter

Gokul Poly Valves Pvt Ltd brings years of expertise to produce and supply diaphragm valves that meet high industry standards. Serving both domestic and international markets, the company emphasizes quality, durability, and responsive customer support.
