Gokul PP Ball Valve Threaded End

Price 2850 INR/ Number

Get a Price/Quote

Gokul PP Ball Valve Threaded End Specification

Channels
Intentional & Domestic Market

Caliber
Gokul Poly Valves Pvt Ltd

Structure
Ball

Connection
Screw End (BSP Threaded)

Pressure
Medium Pressure

Material
Plastic

Usage
Industrial & Water Application

Media
Water

Size
1/2" To 4"

Temperature of Media
80 Celsius (oC)

Product Type
PP Screw End Ball Valve

Port Size
1/2" To 4"

Color
White

Flange
BSP Threaded

Finish
Polypropylene (PP)

Application
industrial and water application

Gokul PP Ball Valve Threaded End Trade Information

Minimum Order Quantity
20 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
20 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About Gokul PP Ball Valve Threaded End

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	"- 15MM TO 100MM- 4ï
Connection End	Screw end (BSP thread)	Standard	As per manufacturer

Material Specification

NO.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	Polypropylene
2)	Body	1	Polypropylene
3)	Ball	1	Polypropylene
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Reliable Performance in Water and Industrial Systems

The Gokul PP Ball Valve Threaded End is specifically constructed to meet the demands of various water and industrial settings. Its medium-pressure tolerance and compatibility with temperatures up to 80C allow for secure and steady flow regulation, making it ideal for diverse operational environments. The latest polypropylene material ensures resistance against corrosion and chemicals, contributing to system longevity and efficiency.

Versatile and Easy Installation

Thanks to its BSP threaded screw-end, this valve fits seamlessly into new or existing piping systems without hassle. Available in multiple port sizes, it provides flexibility for various piping configurations. Whether you are serving the domestic or intentional market, the valve is designed for straightforward installation and dependable operation.

FAQs of Gokul PP Ball Valve Threaded End:

Q: How do I install the Gokul PP Ball Valve Threaded End?

A: Installation is straightforward due to the BSP threaded screw-end connection. Simply align the threads with your pipe fittings and tighten securely to prevent leakage. Ensure compatibility with pipe sizes ranging from 1/2" to 4" as per your system requirements.

Q: What applications is this ball valve suitable for?

A: This ball valve is engineered for both industrial and water applications, handling everything from general water supply systems to process piping in factories or commercial installations.

Q: When should I choose a polypropylene (PP) valve over a metal one?

A: A polypropylene valve is ideal when corrosion resistance, light weight, or chemical compatibility is important, especially in environments where water or non-aggressive fluids at temperatures up to 80C are handled.

Q: Where is the Gokul PP Ball Valve manufactured and supplied?

A: Produced by Gokul Poly Valves Pvt Ltd in India, the valve is available for export, domestic sales, and is distributed by manufacturers, suppliers, and service providers.

Q: What is the process for using this ball valve in a system?

A: Once installed, you operate the ball valve by turning the handle to open or close the water or fluid flow as needed. The ball structure inside ensures a reliable shutoff and easy operation.

Q: What are the benefits of using this ball valve for water and industrial applications?

A: Benefits include high durability, corrosion resistance, simple installation, and maintenance. Its medium-pressure rating and compatibility with various sizes and temperatures make it versatile for a range of uses.
