Polypropylene Ball Valve Flanged

About Polypropylene Ball Valve Flanged

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Robust Structure and Versatile Sizing

With a sturdy ball valve mechanism and flanged connection, this valve excels in isolating and controlling water in industrial and domestic settings. The wide size range from 1/2" to 12" makes it adaptable to various network systems, ensuring compatibility for diverse operational requirements.


Polypropylene Advantage

Crafted from Polypropylene (PP), the valve resists chemical corrosion and stands up to harsh conditions in industrial environments. Its medium pressure rating and smooth finish contribute to enhanced durability and longevity, meeting the demands of rigorous water applications.


Exported QualityMade in India

Gokul Poly Valves Pvt Ltd manufactures and exports these valves from India, maintaining high standards for global and domestic use. As a trusted manufacturer, supplier, and service provider, the company ensures consistent product quality for industrial water management.
