Polypropylene Ball Valve Threaded End

About Polypropylene Ball Valve Threaded End

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	"- 15MM TO 100MM- 4ï
Connection End	Screw end (BSP thread)	Standard	As per manufacturer

Material Specification

NO.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	Polypropylene
2)	Body	1	Polypropylene
3)	Ball	1	Polypropylene
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Durable Polypropylene Construction

Manufactured from premium polypropylene plastic, this ball valve offers excellent resistance to corrosion and chemical attacks, making it ideal for rigorous industrial and water system applications. Its robust material supports prolonged use even under medium pressure and elevated water temperatures, ensuring reliability.


Versatile Sizing and BSP Threaded Ends

Available in port sizes from 1/2" to 4", this valve features BSP threaded screw ends for easy, secure connection. Installation is straightforward and compatible with standard piping systems, streamlining integration into new and existing setups in both industrial and domestic contexts.


Optimized for Water and Industrial Use

Designed to perform with water media up to 80C, this valve meets the demands of both industrial processes and water supply networks. It is widely used for water distribution, treatment plants, and other fluid control environments, offering efficient shut-off and flow regulation.
