PP Ball Screwed End Valve

About PP Ball Screwed End Valve

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	"- 15MM TO 100MM- 4ï
Connection End	Screw end (BSP thread)	Standard	As per manufacturer

Material Specification

NO.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	Polypropylene
2)	Body	1	Polypropylene
3)	Ball	1	Polypropylene
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Robust Polypropylene Construction

With its polypropylene build, this valve delivers enhanced durability, corrosion resistance, and dependable performance in demanding environments. The white finish adds to its clean appearance, making it suitable for visible installations where cleanliness is essential and longevity is paramount.


Versatile Application Range

Designed to serve both industrial and water-related systems, this ball valve adapts flexibly to processes requiring reliable shut-off and regulation. Available in sizes from 1/2" to 4", it can be deployed across multiple scales, making it an excellent choice for both domestic and commercial projects.


Temperature & Pressure Reliability

Engineered to withstand media temperatures up to 80C and perform under medium pressure conditions, this valve ensures stable operation. Its robust structure and screw-end BSP threaded connection further contribute to safety, efficiency, and ease of maintenance.
