PP Ball valve Flange End 3/4"

About PP Ball valve Flange End 3/4"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Flanged Connection for Secure Installation

The flanged end design of this PP ball valve ensures easy and secure mounting to compatible pipeline systems, providing leak-proof operation and stability. The 150-class flange offers strength and adaptability for medium-pressure water and industrial processes.


Quality Polypropylene Construction

Crafted from high-grade polypropylene (PP), the valve exhibits excellent resistance to corrosion, scaling, and harsh chemicals. Its white finish reflects cleanliness and suitability for potable water and various industrial fluids.


Versatility in Industrial and Water Applications

This valve is tailored for both industrial processes and water management projects. Its capability to withstand up to 80C makes it suitable for diverse media, ensuring consistent performance across different applications.
