PP Ball Valve Flange Type

About PP Ball Valve Flange Type

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF-LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF-LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Robust Polypropylene Construction

Our ball valves are made from high-quality PP (polypropylene), which provides excellent durability, resistance to most chemicals, and long service life in demanding environments. The white finish ensures it remains unaffected by rust, making it especially suitable for water and industrial applications.


Versatile Flanged Design

The flanged connection, adhering to 150 class standards, ensures easy and leak-proof installation. This design is ideal for both new pipelines and retrofitting, offering secure integration with a wide range of pipe sizes from 1/2" to 12".


Thermal Performance and Safety

Specifically developed for medium-pressure systems, this PP Ball Valve operates safely with liquids up to 80C. This makes it highly compatible with diverse industrial and water handling processes, where consistent temperature management is crucial.
