Gokul 3pc. Flanged End PP Ball Valve

Price 41150 INR/ Number

Get a Price/Quote

Gokul 3pc. Flanged End PP Ball Valve Trade Information

Minimum Order Quantity
10 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
10 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About Gokul 3pc. Flanged End PP Ball Valve

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Teflon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12ïï-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEFLON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEFLON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Durable and Versatile Flanged Ball Valve

Designed for industrial and domestic water management, the Gokul 3pc. Flanged End PP Ball Valve combines longevity and versatility. The polypropylene material resists chemicals, while the robust flange face ensures secure, leak-free connections across installations. This makes the valve ideal for challenging environments and various fluid control scenarios.

Precision Engineering by Gokul Poly Valves Pvt Ltd

Gokul Poly Valves Pvt Ltd, a reputable exporter and supplier from India, delivers this ball valve with a focus on quality and performance. The 3pc. design ensures easy maintenance, while a temperature rating of 80C and suitability for medium pressure operations guarantee dependable service for both industrial processes and water distribution systems.

FAQs of Gokul 3pc. Flanged End PP Ball Valve:

Q: How should the Gokul 3pc. Flanged End PP Ball Valve be installed?

A: Installation requires aligning the valves 150 class flanges with pipeline flanges, then securely bolting them together using appropriate gaskets. Ensure compatibility with a port size ranging from 1/2" to 12" for optimal fit and performance.

Q: What are the main benefits of using a polypropylene (PP) ball valve in water and industrial applications?

A: Polypropylene is resistant to corrosion and many chemicals, ensuring longevity and reducing maintenance. This makes the valve ideal for water and various industrial fluids, providing reliable shut-off and flow control.

Q: When is it suitable to use this valve in your process systems?

A: This valve is suitable when fluid temperatures do not exceed 80C and when operating at medium pressure, making it ideal for both domestic water supply lines and industrial processing plants.

Q: Where can these valves be sourced, and what markets do Gokul Poly Valves Pvt Ltd serve?

A: They can be sourced directly from Gokul Poly Valves Pvt Ltd, which serves both the intentional and domestic markets in India, as well as acting as an exporter and supplier for global needs.

Q: What is the maintenance process for the Gokul 3pc. Flanged End PP Ball Valve?

A: Routine maintenance involves periodic inspection of the seals, bolts, and flange connections to ensure no leaks or signs of wear. Thanks to the 3pc. structure, internal parts can be accessed and serviced without removing the entire valve from the line.

Q: What types of media can be controlled using this valve?

A: This valve is specifically designed for water and compatible industrial fluids, given its plastic (polypropylene) body and construction, ensuring effective and safe operation in relevant environments.
