Gokul Polypropylene Diaphragm Valve Flange End 4"

Price 6660 INR/ Number

Get a Price/Quote

Gokul Polypropylene Diaphragm Valve Flange End 4" Specification

  • Caliber
  • Gokul Poly Valves Pvt Ltd
  • Pressure
  • Medium Pressure
  • Channels
  • Intentional & Domestic Market
  • Connection
  • Flanged
  • Structure
  • Ball
  • Usage
  • Industrial & Water Application
  • Material
  • Plastic
  • Media
  • Water
  • Size
  • 4"-100MM
  • Temperature of Media
  • 80 Celsius (oC)
  • Product Type
  • PP Diaphragm Valve Flange End
  • Port Size
  • 4"-100MM
  • Flange
  • 150 class
  • Color
  • White
  • Finish
  • Polypropylene (PP)
  • Application
  • industrial and water application


Gokul Polypropylene Diaphragm Valve Flange End 4" Trade Information

  • Minimum Order Quantity
  • 10 Number
  • FOB Port
  • Ahmedabad
  • Payment Terms
  • Cash Advance (CA), Cash in Advance (CID), Cheque
  • Supply Ability
  • 10 Per Day
  • Delivery Time
  • 1 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Box Packing
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO & Material Test Certificate


About Gokul Polypropylene Diaphragm Valve Flange End 4"

Technical Specification

Material Of Construction PP (Polypropylene) Construction weir type design,Soft seated, raising stem
Design 2 Piece Design Connection End Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.
Size Range 15MM to 150MM Test pressure 6 kg./cm2
Max working temp 70 c (consistently) Standard As per manufacturer

Material Specification

No. DESCRIPTION MATERIAL QTY.
1) Body Polypropylene 1
2) Bonnet Polypropylene 1
3) Hand wheel Polypropylene 1
4) Diaphragm Neoprene Rubber 1
5) Compressor PP 1
6) Stem / Spindel M.S. /Brass 1
7) Nut M.S./ S.S. 1
8) Pin M.S./ S.S. 1
9) Bolt, Nut, Washer M.S./ S.S. REQ
10) Cap Polypropylene 1


Durable Polypropylene Construction

Crafted from high-quality Polypropylene, the valve resists corrosion and chemical attacks, making it an optimal choice for rigorous industrial and water processing environments. Its medium pressure rating and flanged ends assure dependable performance and easy maintenance, reducing downtime.


Designed for Versatile Applications

Gokul Polypropylene Diaphragm Valves are purpose-built for industrial and domestic water usage. Their advanced ball structure and dependable sealing accommodate a variety of flow management needs, delivering consistent results in medium-temperature and pressure settings.

FAQs of Gokul Polypropylene Diaphragm Valve Flange End 4":


Q: How is the Gokul Polypropylene Diaphragm Valve installed in pipeline systems?

A: The valve features a flanged end design, compatible with 150 class flange connections. Installation is straightforward, requiring standard bolting procedures to the pipeline, ensuring secure and leak-proof fitting.

Q: What are the main benefits of using this Polypropylene diaphragm valve in water and industrial applications?

A: This valve offers strong chemical resistance, durability under medium pressure, and reliable operation up to 80C. Polypropylene construction ensures minimal maintenance and maximizes service life, particularly in corrosive environments.

Q: When should this 4" diaphragm valve be selected for fluid control systems?

A: It is best chosen when there is a need for moderate-pressure regulation, chemical resistance, and dependable sealing in water processing or industrial fluid flow systems. The 4" size suits pipelines requiring significant throughput.

Q: Where can the Gokul Polypropylene Diaphragm Valve be used?

A: The valve is suitable for use in water treatment plants, industrial process pipelines, and any system requiring medium pressure fluid control. Its design supports both domestic and intentional market requirements.

Q: What is the process for maintaining the valves performance over time?

A: Routine inspections should check for proper flange integrity and valve operation. Periodic cleaning and checks for any signs of wear or chemical degradation will ensure continued reliable performance.

Q: How can this valve enhance the safety and efficiency of industrial operations?

A: By providing robust resistance to chemicals and maintaining effective sealing even at elevated temperatures, the valve helps reduce leaks, enhance operational safety, and improve productivity in fluid applications.
