Polypropylene Ball Valve Screwed End

Price 360 INR/ Number

Get a Price/Quote

Polypropylene Ball Valve Screwed End Specification

Structure
Ball

Channels
Intentional & Domestic Market

Pressure
Medium Pressure

Caliber
Gokul Poly Valves Pvt Ltd

Connection
Screw End (BSP Threaded)

Material
Plastic

Usage
Industrial & Water Application

Media
Water

Size
1/2" To 4"

Temperature of Media
80 Celsius (oC)

Product Type
PP Screw End Ball Valve

Port Size
1/2" To 4"

Color
White

Flange
BSP Threaded

Finish
Polypropylene (PP)

Application
industrial and water application

Polypropylene Ball Valve Screwed End Trade Information

Minimum Order Quantity
20 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
10 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About Polypropylene Ball Valve Screwed End

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	3 piece design, 1 piece stem (spindle), full bore, Tef lon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	"- 15MM TO 100MM- 4ï
Connection End	Screw end (BSP thread)	Standard	As per manufacturer

Material Specification

NO.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	Polypropylene
2)	Body	1	Polypropylene
3)	Ball	1	Polypropylene
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEF LON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEF LON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Durable Polypropylene Construction

Built using high-quality polypropylene, this ball valve resists corrosion and chemical wear, making it ideal for rigorous industrial environments as well as domestic water systems. The robust material ensures longevity and dependable performance even under medium pressure.

Versatile Size Range & Easy Installation

Offered in port sizes from 1/2" to 4", the valve caters to diverse system requirements. Thanks to BSP threaded screw ends, installation and maintenance are straightforward, reducing downtime and labor costs for both new and retrofit projects.

FAQs of Polypropylene Ball Valve Screwed End:

Q: How is the Polypropylene Ball Valve Screwed End installed?

A: Installation is simple via its BSP threaded screw ends. This design allows for direct connection to compatible pipelines without special tools, ensuring a secure and leak-free fit.

Q: What is the main benefit of using polypropylene as the valve material?

A: Polypropylene offers excellent resistance to corrosion and chemical damage, which extends the valves lifespan and reliability, making it well-suited for both industrial and water applications.

Q: When should this valve be used for an application?

A: This valve is ideal for controlling water or other compatible fluids at temperatures up to 80C and medium pressure settings, making it suitable for both industrial and domestic systems that require durable, non-corrosive components.

Q: Where can the Polypropylene Ball Valve be used?

A: It is suitable for installation in a wide range of locations, including industrial process lines, water distribution systems, and various domestic water applications where reliable shut-off and flow control is needed.

Q: What is the process for operating the valve?

A: Operation involves turning the handle, which rotates the internal polypropylene ball to open or close the flow channel. This straightforward mechanism ensures fast and precise control over fluid movement.

Q: How does the valve benefit an industrial user?

A: Industrial users benefit from its maintenance-free design, corrosion resistance, and ability to handle medium pressures and moderately high temperatures, all of which minimize downtime and ensure consistent system performance.
