polypropylene Diaphragm Flange End Valve 1"

Price 460 INR/ Number

Get a Price/Quote

polypropylene Diaphragm Flange End Valve 1" Specification

Usage
Industrial & Water Application

Size
1"-25MM

Product Type
PP Diaphragm Valve Flange End

Color
White

polypropylene Diaphragm Flange End Valve 1" Trade Information

Minimum Order Quantity
20 Number

FOB Port
Ahmedabad

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
10 Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Box Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO & Material Test Certificate

About polypropylene Diaphragm Flange End Valve 1"

Technical Specification Material Of Construction PP (Polypropylene) Construction weir type design,Soft seated, raising stem Design 2 Piece Design Connection End Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD. Size Range 15MM to 150MM Test pressure 6 kg./cm2 Max working temp 70 c (consistently) Standard As per manufacturer Material Specification No. DESCRIPTION MATERIAL QTY. 1) Body Polypropylene 1 2) Bonnet Polypropylene 1 3) Hand wheel Polypropylene 1 4) Diaphragm Neoprene Rubber 1 5) Compressor PP 1 6) Stem / Spindel M.S. /Brass 1 7) Nut M.S./ S.S. 1 8) Pin M.S./ S.S. 1 9) Bolt, Nut, Washer M.S./ S.S. REQ 10) Cap Polypropylene 1

FAQs of polypropylene Diaphragm Flange End Valve 1":

Q: What is the size and port dimension of the Polypropylene Diaphragm Flange End Valve?

A: The size and port dimension of the valve is 1" or 25MM.

Q: What is the maximum temperature of media that the valve can handle?

A: The valve can operate with a media temperature of up to 80C.

Q: What type of pressure is the valve suitable for?

A: The valve is designed for medium pressure applications.

Q: What is the material used for manufacturing this valve?

A: The valve is made of polypropylene (PP) plastic material.

Q: What type of connection does the valve use?

A: The valve uses a flanged connection and is classified as 150 class.

Q: What are the main applications of this valve?

A: The valve is suitable for industrial applications and water handling purposes.

Q: What type of structural design does the valve have?

A: The valve has a ball structure design.
