pp ball valve 1/2"

About pp ball valve 1/2"

Technical Specification

Material Of Construction	PP (Polypropylene) / HDPE(Highdensitypolyethylene) / PVDF(Polyvinylidene fluoride)	Construction	3 piece design, 1 piece stem (spindle), full bore, Teflon seated
Design	3 piece design	Test pressure	08 kg./cm2
Max working temp	70 c (consistently)	Size Range	" 15MM TO 12-315MM
Connection End	Flanged as per ANSI B 16.5 (150#) &BS 10 (Table D/E/F) & DIN STD.	Standard	As per manufacturers

Material Specification

No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEFLON)
6)	Body"O"Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEFLON)
8)	Stem "O" Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

High-Performance Ball Valve for Varied Applications

Designed for versatility, this PP ball valve is ideal for use in both industrial and water supply systems. The polypropylene construction offers outstanding chemical resistance, while the temperature rating of up to 80C ensures safety and reliability even in moderately hot conditions. Its medium-pressure capacity and sturdy ball-based mechanism help maintain consistent flow control.


Precision Manufacturing by Gokul Poly Valves Pvt Ltd

Produced by a trusted Indian manufacturer and exporter, these ball valves reflect stringent quality standards. The precision flanged connection (150 class) ensures leak-free integration into piping systems, and the white finish offers easy visibility in diverse installation environments. This product is highly regarded for its durability and performance.
